Autodesk Revit

FlyBy

Browse the data of interest either from the active view or from entire project.

Feature 1 &quot;Browser Type&quot;

Sort the data of interest by 4 options:

<ul>
	<li>Category</li>
	<li>Level</li>
	<li>Phase</li>
	<li>Workset</li>
</ul>

Feature 2 &ldquo;Sort By&rdquo;

Easily search for required element

Feature 3 &ldquo;Search Bar&rdquo;

Apply changes to selected element/s.

Feature 4 &ldquo;Modifying Actions&rdquo;

Select or deselect all elements sorted in the window or deselect.
&nbsp;

Feature 5 &ldquo;Selection Buttons&rdquo;

Easily open any view by double- clicking on its name.

Feature 6 &ldquo;Open Views&rdquo;

Add any element by dragging the family from the window and into the canvas.

Feature 7 &ldquo;Place Element&rdquo;

An alert that a change has occurred.

Feature 8 &ldquo;Sync Button&rdquo;

Refresh to load latest updates.

Highlight selected element/s in model

Isolate and not isolate selected element/s

Delete selected element/s.

Example of a change in action using the Browser Tool.

A study how a Revit user can revise and audit a model using the Browser Tool.

A study how a Revit user can know the view that on sheet and not on sheet to delete the unneeded view using the Browser Tool.

Browser Tool helps in saving workflow time in modeling, auditing and visualizing. It is used to browse, select, and navigate through model components, views, and sheets, and easily update associated data with enhanced filtering power. Browser Tool assists in applying model maintenance and validation standards to the model.
&nbsp;

Open Views

Browser

Select the type of inserted link &ldquo;Revit,IFC,CAD,Image,PDF,CAD Imported&rdquo;.

Feature 1 &ldquo;Filter&rdquo;

Relative: Location is in a working directory
Absolute: Location is in a shared path

Feature2 &ldquo;Path Type&rdquo;

Attached: Loads link and its nested models
Overlay: Loads only the linked model

Feature 3 &ldquo;Attachment Type&rdquo;

Select All: Select all links in window
Select None: Deselect all links in window

Feature 4 &ldquo;Select &rdquo;

Feature 5 &ldquo;Update&rdquo;

Feature 6 &ldquo;Link Status&rdquo;

Reloads selected link in project.

Update the linked file from different path.

Unloads selected link from project.

Repath / Update a number of linked models of a complex project, Links Manager Tool enables that in a few minutes

Links Manager is used to manage, re-path, audit, and update all model links (Rvt, CAD, IFC, PDF, Image, ..)&nbsp; globally.&nbsp;

Links Manager

Feature 1 &ldquo;Modification&rdquo;

Checks the accuracy and validity of the current spreadsheet.

Feature 2 &ldquo;Validate&rdquo;

Export Excel: Saves the current spreadsheet into an excel sheet
Import Excel: Loads an excel sheet into the current spreadsheet

Feature 3 &ldquo;Import/Export excel sheet&rdquo;

Choose the type of text inside each cell.

Feature 4 &ldquo;Format &rdquo;

Selects any of all the schedules in the active project.

Feature 5 &ldquo;Schedule type&rdquo;

Write the Material names &amp; Comments.

Feature 6 &ldquo;Material &amp; Comments&rdquo;

Feature 7 &ldquo;Update&rdquo;

Erases the last change done.

Get the last change done back again.

Copy data from any cell to another.

Paste the copied data from cell to selected one.

Drag the curse to apply the same change to other cells.

Remove the data from. a selected Cell

Update a number of parameters in several schedules in a complex project, Schedule Manager Tool enables that in a few minutes

Schedule Manager is used to manage all the schedules and update parameters instantly.

Schedule Manager

Genesis

Apply changes to selected cell.
&nbsp;

Feature 1 &ldquo;Modification&rdquo;

Write the levels names &amp; heights.

Feature 2 &ldquo;Name &amp; Height&rdquo;

Save the current spreadsheet into an excel sheet.

Feature 3 &ldquo;Export Excel&rdquo;

Feature 4 &ldquo;Create&rdquo;

Remove the data from a selected Cell.

Example of creating&nbsp; new levels in a project in no time using Levels Creator Tool.

Levels Creator Tool helps in saving time in setting up a new project. It is used to easily generate multiple adjacent levels with a few clicks.

Levels Creator

Choose one of the loaded titleblocks.

Feature 1 &ldquo;TitleBlock&rdquo;

Feature 2 &ldquo;Modification&rdquo;

Add / Remove parameter on the sheets.

Feature 4 &ldquo;Add / Remove Parameter&rdquo;

Feature 5 &ldquo;Sheet Name , Number &amp; Title Block Name&rdquo;

Feature 6 &ldquo;Create&rdquo;

Example of creating new sheets in a project in no time using Sheets Creator Tool.

Sheets Creator Tool can be used to easily generate new &amp; manage a long list of multiple sheets with a few clicks.

Sheets Creator

Feature 2 &ldquo;Name&rdquo;

Apply the new worksets to the project.

Feature 4 &ldquo;Create&rdquo;

Example of creating new Worksets in a project in no time using Worksets Creator Tool.

Worksets Creator Tool can be used to easily create all project worksets in seconds.

Worksets Creator

Select an existing documentation set.

Feature 1 &ldquo;Select Sheetlist&rdquo;

&nbsp;Create a new table of content for a documentation set.

Feature 2 &ldquo;New Sheetlist&rdquo;

Feature 3 &ldquo;Modification&rdquo;

&nbsp;Save the current spreadsheet into an excel sheet.

Feature 4 &ldquo;Export Excel&rdquo;

Apply the new sheetlist to the project.

Feature 5 &ldquo;Create&rdquo;

Example of creating a new sheetlist in a project in no time using Sheetlist Creator Tool.

Sheetlist Creator Tool can be used to easily create a table of content for a documentation set.

FlyBy

Genesis

Blackhole

Questions & Answers

Q1

Q2

What is Revit Plugins ?

Plugins are external additions installed inside the Revit in a new tab. These add-ins are customized to count up extra features to Revit to enhance its capabilities without having any impact on the native Revit.

Q3

Q4

How to install Singularity plugins inside Revit ?

- This app uses a custom installer.

Run the downloaded installer and continue with the instructions.

Compatibility

Windows 7,8,9 and 10
Revit 2018, 2019, 2020, 2021, 2022, 2023 and 2024
